QRP Labs QCX-mini CW User Manual

3.7 Install capacitors C25 and C26 from Low Pass Filter kit
The value of these capacitors depends on your chosen band. The capacitors are located
inside the separate Low Pass Filter bag in your main kit bag. Refer to the following table to
find the correct capacitor value for your band:
Band Value Label
80m 1200pF “122”
60m 1200pF “122”
40m 680pF “681”
30m 560pF “561”
20m 390pF “391”
17m 270pF “271”
 33
