QRP Labs QCX-mini CW User Manual

3.8 Install capacitors C27 and C28 from Low Pass Filter kit
The value of these capacitors depends on your chosen band. The capacitors are located
inside the separate Low Pass Filter bag in your main kit bag. Refer to the following table to
find the correct capacitor value for your band:
Band Value Label
80m 470pF “471”
60m 680pF “681”
40m 270pF “271”
30m 270pF “271”
20m 180pF “181”
17m 100pF “101”
 34
