Quasar Palmcorder VM-D52 User Manual

25
Special Features
Before you begin...
• Connect Camcorder to power source.
• Set POWER to CAMERA.
1 Press MENU for
MENU mode.
Press UP or DOWN
to select
VIDEO EFFECTS .
2 Press DISPLAY for
VIDEO EFFECTS
menu. Press UP or
DOWN to select
AUTO FADE .
3 Press DISPLAY for
AUTO FADE ;
COLOR menu.
Press UP or DOWN
to select BLACK or
WHITE.
4 Press DISPLAY to confirm entry.
Press MENU to exit.
Fade In:
In RECORD/PAUSE mode, press FADE
so “FADE” flashes in EVF.
Press RECORD/PAUSE.
Recording starts as picture and sound
gradually fade in.
Fade Out:
While recording, press FADE so “FADE”
flashes in EVF.
Press
RECORD/PAUSE.
Picture and sound gradually fade out, and
recording is paused.
If
FADE is pressed accidentally, press again
so “FADE” disappears in EVF.
An interesting way to open and close
scenes.
Auto Fade
Fade Out
BLACKWHITE
Fade In
RECORD/
PAUSE
1, 2, 3, 4
FADE
