GL200 Manage Tool User Guide
TRACGL200MT002 - 32 -
Step_2: The command message which shall be sent to GL200 will be generated based on input
and displayed here. Please note this command message can also be sent to GL200 through
SMS or GPRS.
Step_3: Set the Digital Output parameters. Please refer to “GL200 @Track Air Interface Protocol”
for the meaning of each parameter.
Step_4: Click the “Send” button; download the parameters of GTOUT to GL200.
3.2.15 Set the parameters of Digital Input Port Setting
Step_1: Select “Digital Input Port Setting”, after that the parameters of GTDIS show in Command
Operation Space.
Step_2: The command message which shall be sent to GL200 will be generated based on input
and displayed here. Please note this command message can also be sent to GL200 through
SMS or GPRS.
Step_3: It is recommended to read the parameters from GL200 and edit based on them.
Step_4: Set the Digital Input parameters. Please refer to “GL200 @Track Air Interface Protocol”
for the meaning of each parameter.
Step_5: Click the “Send” button; download the parameters of GTDIS to GL200.
Step_1
Step_2
Step_4
Step_5
Step_3
