Queclink GL200 User Manual

GL200 Manage Tool User Guide
TRACGL200MT002 - 34 -
Step_1: Select “transparent data transmission”, after that the parameters of GTDAT show in
Command Operation Space.
Step_2: The command message which shall be sent to GL200 will be generated based on input
and displayed here. Please note this command message can also be sent to GL200
through SMS or GPRS.
Step_3: Set the Transparent Data Transmission parameters. Please refer to “GL200 @Track Air
Interface Protocol” for the meaning of each parameter.
Step_4: Click the “Send” button; download the parameters of GTDAT to GL200.
3.2.18 Set the parameters of White Call List Configuration
Step_1: Select “White Call List Configuration”, after that the parameters of GTWLT show in
Command Operation Space.
Step_2: The command message which shall be sent to GL200 will be generated based on input
and displayed here. Please note this command message can also be sent to GL200 through
SMS or GPRS.
Step_3: It is recommended to read the parameters from GL200 and edit based on them.
Step_4: Set the
White Call List parameters. Please refer to “GL200 @Track Air Interface
Protocol” for the meaning of each parameter.
Step_5: Click the “Send” button; download the parameters of GTWLT to GL200.
Step_1
Step_2
Step_4
Step_3
Step_5
Queclink
Confidential
