GL300 @Tracker Air Interface Protocol
3. Message Description
3.1. Message Format
All of the @Track Air Interface Protocol messages are composed of printable ASCII characters.
Each message has the following format:
Message format Message type
AT+GTXXX=<parameter1>,<parameter2>,…$ Command
+ACK:GTXXX,<parameter1>,<parameter2>,…$ Acknowledgement
+RESP:GTXXX,<parameter1>,<parameter2>,…$ Report
The entire message string ends with character ‘$’.
The characters ‘XXX’ identify the deferent message.
The “<parameter1>,<parameter2>,…” carry the message’s parameters. The number of parameters
is different in different messages. The ASCII character ‘,’ is used to separate the neighbouring
parameter characters. The parameter string may contain the ASCII characters:
‘0’-‘9’, ’a’-‘z’, ’A’-‘Z’.
Detailed descriptions of each message format are located in the specific message sections.
By sending Commands to the terminal, the backend server can either configure and query the
parameters of the terminal or control the terminal to perform specific actions. When the terminal
receives Commands over the air, it will reply with a corresponding Acknowledgement message.
According to the configuration of the parameters, the terminal can send Report messages to the
backend server. Please see the following figure:
T
erminal
Backend
Server
Command
Acknowledgement
Report
Report
Report
Figure 2: @Tracker protocol messages flow
TRACGL300AN001 - 10 -
