7 Reliability, Radio and Electrical
Characteristics
7.1. Absolute Maximum Ratings
Absolute maximum ratings for power supply and voltage on digital and analog pins of the module are
listed in the following table.
Table 42: Absolute Maximum Ratings
7.2. Power Supply Ratings
Table 43: Power Supply Ratings
Parameter
Min.
Max.
Unit
VBAT
-0.5
6
V
USB_VBUS
-0.5
16
V
Peak Current of VBAT
-
3
A
Voltage on Digital Pins
-0.3
2.16
V
Parameter
Description
Conditions
Min.
Typ.
Max.
Unit
VBAT
VBAT
The actual input voltages must
stay between the minimum and
maximum values
3.5
3.8
4.4
V
Voltage drop during
transmitting burst
Maximum power control level at
EGSM900
-
-
400
mV
IVBAT
Peak supply current
(during transmission slot)
Maximum power control level at
EGSM900
-
1.8
3.0
A
