Quincy Compressor QSI Series User Manual

Section IV - Operating Procedures
28 Quincy Compressor-QSI
®
• 
• If an input is in warning or shutdown, the original icon is replaced by the warning or shutdown icon respectively

Outputs menu
Control panel
(1) Scroll keys
(2) Enter key
(3) Back key
Menu icon, Outputs
Function
To call up information regarding the actual status of some outputs such as the condition of the Fan overload contact

Procedure

• 
1
3
2
