6
2. General information
2.1 Technical data
Processor CPU Embedded ARM920T, 203 MHz, fan-less
Memory
Program Memory 32 MB FLASH ROM
Working Memory 32 MB SDRAM
Data Memory 16 MB FLASH ROM
Temporary Memory 1 MB SRAM (battery buffered)
Memory Expansion SD card slot
Display
Operator Display 12.1“ TFT-Color-LCD, anti-glare
Touch Screen 4 wire resistive
Resolution 800 x 600 pixel
Adjustable Tilt Angle 0° - 140° (Concerto only)
Customer Display Graphical VFD, 140 x 16 pixel (optional)
Keyboard Internal 156 keys flat, spill-proof (Concerto only)
Interfaces
Serial 2 x RS232 + 4 x RS232 (optional)
USB 2 x Host
LAN/Ethernet 1 x RJ45 (optional)
Cash Drawer 2 x RJ11
Card Reader 1 x Smart Card, 1 x SIM Card (optional)
Clerk Key Lock Magnetic Dallas i-Button
Software
Operating System Embedded Linux
Application QMP – Quorion Multi Purpose
Max. Number of PLU’s 50,000
Max. Number of Departments 999
Max. Number of Clerks 999
Max. Number of Sales Persons 999
Max. Number of Tables 10,000
Max. Number of Customer Reports 99
Specifications
Dimensions (LxWxH)
380 x 330 x 95 mm (Concerto)
275 x 315 x 65 mm (QTouch
2
)
Weight
6.2 kg (Concerto)
3.2 kg (QTouch
2
)
Power Supply External AC adapter, 110 … 240 V
Operating Temperature 0 … +40°C
Storage Temperature -10 … +50°C
Please note, that all indicated parameters are maximum values, which can only be reached with
corresponding hardware expansion (additional memory) and configuration!
