RADWIN2000CPlusUserManual Release3.5.70 7‐8
Management Chapter7
4.ClickOKtosaveyourchoice.
Notethatforeachactivetrapdest ination,theClearTrapDestinationbuttonisenabled:
VLANforManagement
ManagementVLANConfiguration
Figure7‐4:VLANforManagement
VLANManagementenablesseparationofusertrafficfrommanagementtrafficwhenever
suchseparationisrequired.Itisrecommendedthateachmemberofasectorbeconfigured
withdifferentVLANIDsformanagementtraffic.(Thisreducesyourchancesofaccidentally
lockingyourselfoutofthelink.)
 ToenableVLANformanagement:
1.InthewindowofFigure 7‐4,checktheEnabledbox.
2.EnteraVLANID.Itsvalueshouldbebetween2and4094.
AfterenteringtheVLANID,onlypacketswiththespecifiedVLANIDareprocessed
formanagementpurposesbytheHBS/HSUODU.Thisincludesalltheprotocolssup‐
portedbytheODU(ICMP,SNMP,TelnetandNTP).UsingVLANformanagementtraf‐
ficaffectsalltypesofmanagementconnections(local,networkandovertheair).
3.EnteraPrioritynumberbetween0and7.
Caution
VLANIDsareusedbyRADWINproductsinthreeseparatecontexts:
ManagementVLAN,TrafficVLANandEthernetRing.Itisrecommendedthat
youusedifferentVLANIDsforeachcontext.
