RADWIN2000D+UserManual Release3.6.00 8‐8
ObtainingReports Chapter8
HereisanextractforthedownlinkPerformanceMonitoringreportbasedon15minutes
recording:
Figure8‐3:Downlink‐PerformanceMonitoringreport‐Validdata
Theon‐screenreportmaybescrolledverticallyandhorizontally.Themeaningofthecolumn
headingsisshowninthefollowingtable:
Table8‐2:HBSPerformanceMonitoringFields
ColumnHeading
Abbreviation
Meaning
Description
Integrity Validdataflag
Greentickforcurre ntandvalid;Redcrossfor
invalidateddata(Seeexamplebelow).Notethatthe
PerformanceMonitoringdataisnotvalidifnotallthe
valueswerestored(e.g.,duetoclockchangeswithin
theintervalorpowerupreset)
Date&Time Timestamp
Dataare recordedevery15minutes;thelast30days
ofrecordingsaremaintained.Roll‐overisatmidnight.
UAS
Unavailable
Seconds
Secondsinwhichtheinterfacewasoutofservice.
ES Erroredseconds
Thenumberofsecondsinwhichtherewasatleast
oneerrorblock.
SES
SevereErrored
Seconds
Thenumberofsecondsinwhichtheservicequality
waslowasdeterminedbytheBBERthreshold.
BBE
Background
BlockError
Thenumberoferroredblocksinaninterval.
RxMBytes
Received
Mbytes
ThenumberofMegabytesreceivedatthespecified
portwithintheinterval
TxMBytes
Transmitted
Mbytes
ThenumberofMegabytestransmittedatthe
specifiedportwithintheinterval.
