RADWIN2000D+UserManual Release3.6.00 7‐17

Management Chapter7

Security

Figure7‐9:SectorSecuritysettings‐RT‐A(HBS)

TheSecuritydialogenablesyoutochangetheLinkPasswordandtheSNMPCommunity

strings.

ChangingtheLinkPassword

Thisitemisavailableasfollows:

• AttheRT‐A(HBS)

• AtanisolatedRT‐B(HSU)

Herearethedetails:

Thedefaultpasswordiswireless‐p2mp.Optionally,youcanchangethelinkpasswordas

explainedhere.

 Tochangethelinkpassword:

1.OpentheSecuritytab(Figure 7‐9).

TheChangeLinkPassworddialogboxopens.

Note

UsetheHide characterscheckboxformaximumsecurity
