RADWIN2000D+UserManual Release3.6.00 4‐13
InstallingaLink Chapter4
MountinganODU
UseamountingkittomountanODUonawallorpole.Anexampleisshowninthefollowing
figure:
ThemountingkithasanextraarmenablestheODUtobemountedatlargeanglesrelativeto
thewallorpole,ortoahorizontalpole,asshown:
Figure4‐14:MountedODU: largeangletowall
MountinganExternalFlatPanelAntenna
Typically,aflatpanelantennasuchasthatshowinFigure 4‐16hasfourboltsforamounting
kitadapter.
Note
• WhenmountinganODUonapoleorwall,ensurethattheunitisori‐
entedsothatthecableconnectorsareatthebottom.
• DonotmountanODUhorizontally
• Ensurethattherearenodirectobstructionsinfrontofanintegrated
antennaODUorinterferencefromman‐madeobstacles.
• Forcompleteinstructionsonusingthemountingkit,seetheincluded
QuickInstallationGuide.
