RADWIN2000D+UserManual Release3.6.00 4‐1
Chapter4:HardwareInstallation
4.1Overview
Thischaptercoverstherequirementsandproceduresforthehardwareinstallationand
alignmentofaRADWIN2000D+sectorinaccordancewithpriorplanning.(SeeSiteSurvey.)It
isintendedtoassistqualifiedfieldtechnicians.
Thischaptercoversthefollowingtopics:
• Unpackingandcheckingsuppliedequipment:
• ODUs
• PoEdevices
• IDU‐Haggregationunit
• Antennas
• Accessories
• Toolsrequiredforinstallation
• Safetypractices
• MountinganODU
• ConnectinganODU
• GroundingandlightningprotectionforanODU
• Networkconnection
• Poweringup
Warning
OutdoorunitsandantennasshouldbeinstalledONLYbyqualifiedfield
technicianswhoarefamiliarwithlocalbuildingandsafetycodesand,
whereverapplicable,arelicensedbytheappropriategov ernment
regulatoryauthorities.Failuretodosomayexposetheenduserorthe
serviceprovidertolegalandfinancialliabilities.RADWINanditsresellersor
distributorsarenotliableforinjury,damageorviolationofregulations
associatedwiththeinstallationofoutdoor unitsorantennas.
Note
ThematerialinthischapterislargelygenerictoallRADWINradioproducts
unlessstatedotherwise.ODUma ybeanHBSoranytypeofHSU.
