RADWIN2000D+UserManual Release3.6.00 4‐9
Toolsrequiredforinstallation Chapter4
Figure4‐12:RADWINLightningProtect or
Thelightningprotectorincorporateshigh‐powergasdischargetubeandcurrenttransistor
protectioninasingleprotectorunit.
EthernetCableRepeater
TheRADWINEthernetrepeaterenablesyoutoextendthePoEtoODUcablebeyondthe
100mlimit(butnomorethan200m).
Figure4‐13:RADWINEthernetCableRepeater
4.3Toolsrequiredforinstallation
ThefollowingisalistoftheequipmentandmaterialsrequiredtoinstallRADWIN2000D+
hardware.
4.3.1ToolsandMaterials
• CrimpingtoolforRJ‐45(iftheODU‐PoEcableiswithoutconnectors)
• Spanner/wrench13mm(½”)
• Drill(forwallmountingonly)
Note
TheEthernetrepeatercannotbeusedwithGbEPoE‐ODUcables.
