RG27/35/37 Operation • Service • Maintenance
42
Maintenance
4) Blade Bushings (If Equipped)
Lubricate 3-4 shots of grease into the grease fittings (1).
Note: there should be 4 total fittings.
5) Steering Axle Pivot Knuckles
Lubricate 3-4 shots of grease into the grease fittings (2) on
both steering knuckles.
6) Steering Axle Cylinder
Lubricate 3-4 shots of grease into the grease fittings (3) on
each end of steering cylinder.
7) Self-propel Axle Flange Bearings
Lubricate 3-4 shots of grease into the grease fittings (4) on
both outer axle flange bearings.
Cutting Wheel - Lubricate
Lubricate the two fittings (5) (one on each side) until you
can visually see old grease being purged out of the side
of the bearing.
Cutting Wheel PolyChain® - Check
& Adjust Tension
Using a belt gauge, check the PolyChain® tension by
depressing the PolyChain® at the center of the span.
1. Remove the PolyChain® guard cover. The cutting wheel
must be free to rotate (eg. not resting on ground).
1
1
3
2 2
4
5
THE MACHINE MUST BE SHUT DOWN WHEN
CHECKING AND ADJUSTING BELT TENSION.
