Chapter 3: Cables and connections
This section contains information regarding the connection of power and equipment to your A-Series display.
Chapter contents
• 3.1 General wiring instructions on page 20
• 3.2 Connection overview on page 21
• 3.3 Power connection on page 22
• 3.4 Sonar transducer connection on page 23
• 3.5 NMEA 0183 connections on page 24
• 3.6 SeaTalk connections on page 25
• 3.7 External GPS Connection on page 26
• 3.8 SeaTalk
ng
connections on page 26
• 3.9 NMEA 2000 connection on page 27
See also
For details of cable spares and accessories refer to Chapter 9: Accessories.
