SECTION 6
6.1 PARTS LIST
******PF PCB Assembly Section******
DESCRIPTION Q'ty Symbol Parts No.
Capacitor
Ceramic, 15pF (2125) 2 C7,361
Ceramic, 33pF (2125) 2 C4,5
Ceramic, 1000pF (3216) 4 C6,12,18,20
Ceramic, 1000pF 61 C9,21,22,23,24,25,26,27,30,31,32,33,35,36,40,8
0,97,106,107,111,115,118,119,502,121,122,124,
126,127,131,133,134,140,141,143,147,149,151,
170,245,246,250,105,362,363,368,377,378,379,
501,381,383,11,14,16,359,360,336,401,403
Ceramic, 0.5pF 3 C137,402,404
Ceramic, 1pF 1 C109
Ceramic, 2pF 3 C13,108,117
Ceramic, 5pF 4 C123,129,132,139
Ceramic, 6pF 1 C136
Ceramic, 7pF (UJ) 1 C113
Ceramic, 8pF 3 C130,138,145
Ceramic, 10pF 1 C110
Ceramic, 15pF 2 C10.34
Ceramic, 10pF (UJ) 1 C114
Ceramic, 18pF 1 C142
Ceramic, 33pF 4 C28,95,144,146
Ceramic, 27pF 1 C29
Ceramic, 39pF 1 C156
Ceramic, 47pF 1 C37
Ceramic, 51pF 1 C94
Ceramic, 56pF 1 C157
Ceramic, 68pF 1 C104
Ceramic, 91pF 1 C153
Ceramic, 220pF 3 C38,159,160
Ceramic, 6800pF 2 C39.102
Ceramic, 2200pF 2 C41.103
Ceramic, 0.1µF 18 C96,150,152,155,158,161,225,228,232,234,334,
364,365,369,382,343,344,384
Ceramic, 0.01µF 6 C167,168,148,172,407,406
Ceramic, 0.022uF 2 C164.101
Tant., 0.1µF /25V 4 C15,99,226,349
Tant., 1µF/16V 7 C42,98,162,169,227,229,332
Tant., 2.2µF/10V 2 C100.223
Tant., 4.7µF/10V 2 C163,222
Tant., 10µF / 16V 8 C45,154,166,224,231,236,116,385
Elec., 4.7µF/25V 1 C335
Elec., 22µF / 16V 1 C44
Elec., 47µF / 16V 1 C337
