Raymarine RAY 210VHF User Manual

41
******CPU PCB Assembly******
DESCRIPTION Q'ty Symbol Parts No.
Capacitor
Ceramic, 33pF 2 C18.19
Ceramic, 100pF 1 C23
Ceramic, 220pF 3 C6,7,8
Ceramic, 1000pF 20 C20,27,28,44,47,48,49,50,51,52,53,54,55,56,57,5
8,59,60,61,62
Ceramic, 4700pF 1 C31
Ceramic, 6800pF 1 C22
Ceramic, 0.047uF 2 C21,29
Ceramic, 0.082uF 1 C100
Ceramic, 0.01µF 2 C4,5
Ceramic, 0.1µF 7 C1,2,3,10,24,26,45
Tant., 0.47µF 25V 2 C25,40
Tant., 1µF 16V 3 C41.42.43
Tant., 1µF 50V 1 C17
Tant., 10µF 16V 10 C14,15,32,33,34,36,37,38,39,64
Elec., 100µF 16V 1 C46
Elec., 220µF 25V 1 C16
Diode
Diode UDZ9.1 1 Dl
Diode DA204K 1 D2
Transistor
Transistor 2SA1298 1 Q9
Transistor 2SC1623 2 Q3,7
Transistor 2SD1767 4 Q4,5,10,11
Transistor DTC114EKA 3 Q1,2,8
Transistor DTC343TK 1 Q6
Resistor
Resistor 10 ohm (3226) 1 R64
Resistor 22 ohm (3226) 1 R14
Resistor 120 ohm (3226) 6 R87,88,89,94,98,99
Resistor 330 ohm (3226) 1 R15
Resistor 0 ohm 1 R44
Resistor 10 ohm 1 R46
Resistor 100 ohm 2 R37.47
Resistor 220 ohm 1 R100
Resistor 330 ohm 1 R42
Resistor 1k ohm 24 R6,7,9,10,11,63,66,67,72,73,74,75,76,77,78,79,8
0,81,82,83,84,85,86,33
Resistor 1.2k ohm 2 R16,31
Resistor 2.2k ohm 4 R24,12,13,95
Resistor 3.3k ohm 2 R26,45
Resistor 4.7k ohm 7 R69,70,71,92,96,175,93
Resistor 5.6k ohm 2 R36,38
Resistor 6.8k ohm 1 R28
Resistor 10k ohm 8 R19,30,35,43,49,50,65,90
Resistor 18k ohm 1 R17
Resistor 22k ohm 3 R22,40,41
Resistor 33k ohm 2 R4,5
