12.5°
12.5°
D11359-1
Planinghullvessels,andsomedisplacementhullvessels,adopta
higherbowanglewhenthevesselisatcruisingspeed.Thismay
raisetheradar’smainradiationangle,andcancausepoordetection
ofnearbytargets.Itmaybenecessarytocompensateforthebow
risetoensureoptimumtargetdetection.Thiscanbeachievedby
ttingawedgeorwashersbetweenthemountingplatformandthe
baseoftheradarscanner,sothattheradarbeamremainsparallel
tothewaterlinewhenthevessel’sbowrisesatcruisingspeed.
D11360-1
1
1
ItemDescription
1Wedgeorwashers
Locationandmounting
33
