Fillcontrol Auto Make-up and degassing — 06.07.2016 - Rev. B English —
8.1.2.2 Fillcontrol Auto 2PS
Manual mode is used to test the functions during commissioning and to service the device.
Manual mode enables you to select the following For performing a test run and service tasks:
• "PU1" or "PU2" pumps.
– For switching the pumps on and off.
• "NS" motor ball valve for degassing the facility and the make-up water.
– Manual actuator for opening or closing.
. Press "Manual" on the controller's operator panel.
– Use the arrow keys at the operator panel to select "P1" or "P2" or "NS" on the
display.
– The selected indicator flashes at the display as a visual signal of the selection.
. Press "OK" on the controller's operator panel.
– The pumps or the motor ball valve are switched on and the displays shows "P1!"
or "P2!" or "NS".
– The display must show values of ≥ 3 bar for the pressure for the activated pump.
. Press "OK" on the controller's operator panel.
– The pumps or the motor ball valve are switched off and "P1!" or "P2!" or "NS"
flashes as visual signal.
. Press "AUTO" to deactivate Manual mode.
– Automatic mode is activated.
2.0 bar
P1! P2 U1 NS
*U1 = no function
8.1.3 Stop mode
Use Stop mode to shut the device down. The controller does not monitor the functions. Except for the display of information, the device
is non-functional in Stop mode.
To execute the Stop mode, proceed as follows:
• Press "Stop" on the controller's operator panel.
– The "Stop" LED at the operator panel illuminates to visually indicate that Stop mode is active.
Note!
The system returns an alarm if the Stop mode is activated for more than 4 hours.
If "Floating alarm contact?" in the Customer menu is set to "Yes", the system outputs the alarm to the group alarm
contact.
Note!
Select Stop mode for device commissioning.
