Reflex iC60N User Manual

Introduction
12
A9MA03EN 02/2012
Description
Reflex iC60 integrated control circuit breaker without Ti24 interface
A 230 V AC power supply terminal block
B Y1/Y2 control input terminal block
C Terminal block for the circuit breaker pole position (open/closed) indication contact
D Terminal block for the circuit breaker trip indication contact
F Isolated terminals
G Circuit breaker pushbutton for manual control and selection of operating mode
H Circuit breaker operating state LED
I Resetting handle for circuit breaker
Reflex iC60 integrated control circuit breaker with Ti24 interface
A 230 V AC power supply terminal block
B Y1/Y2 control input terminal block
C Terminal block for the circuit breaker pole position (open/closed) indication contact
D Terminal block for the circuit breaker trip indication contact
E Ti24 interface terminal block
F Isolated terminals
G Circuit breaker pushbutton for manual control and selection of operating mode
H Circuit breaker operating state LED
I Resetting handle for circuit breaker
F
Local control
auto
OFF
Reflex iC60N
A
B D C
F
Ready-Mode1.2.3
I. ON
O. OFF
Overheat
1211 14
21 22 24
O/C
auto/
OFF
Y1 Y2
N
P
A9C5pppp
Mode 1
Mode 2
H
G
I
Local control
auto
OFF
Reflex iC60N
1211 14
21 22 24
O/C
auto/
OFF
Y1 Y2
N
P
FCD
A
B
FE
Ready-Mode1.2.3
I. ON
O. OFF
Overheat
A9C6pppp
Mode 1
Mode 2
Mode 3
H
G
I
