Reflex iC60N User Manual

Installation
14
A9MA03EN 02/2012
Assembly
Introduction
A Vigi iC60 optional auxiliary can be added to the Reflex iC60 integrated control circuit breaker.
Assembly procedure with Vigi iC60 A9V••••• auxiliary
Step Action
1 Pull out the padlocking device
2 Check that the handle is in OFF position (circuit breaker open)
3 Remove the blanking plate on the right-hand side of the Reflex iC60 circuit breaker using a screwdriver
4 Assemble the Vigi iC60 auxiliary with the Reflex iC60 circuit breaker
5 Place the assembly on the DIN rail and push in the 5 locking clips
6 Push the padlocking device back in
Local control
auto
OFF
Reflex iC60N
A9Vppppp
Ready-Mode1.2.3
I. ON
O. OFF
Overheat
1211 14
21 22 24
O/C
auto/
OFF
Y1 Y2
N
P
5
5
auto
OFF
Reflex iC60N
1
Ready-Mode1.2.3
I
.
ON
O
.
OFF
O
verheat
2
Vigi iC60 25 A
Vigi iC60 40 A A9Vppppp
Vigi iC60 63 A
auto
OFF
Reflex iC60N
Ready-Mode1.2.3
I. ON
O
. OFF
O
v
erheat
auto
OFF
6
Reflex iC60N
Ready-Mode1.2.3
I. ON
O. OFF
Overheat
3
4
