RL78/G13 Safety Function (Frequency Detection)

5.8.12 Starting Channel 5 of TAU0

Figure 5.15 shows the flowchart for starting channel 5 of TAU0.

R_TAU0_Channel5_Start()

Start channel 5 of TAU0

return

TMIF05 bit  0: Clear interrupt request flag.

TMMK05 bit  0: Enable interrupt processing for channel 5 of TAU0

TS0 register  0020H

Figure 5.15 Starting Channel 5 of TAU0

R01AN0956EJ0100 Rev. 1.00 Page 43 of 70

Feb. 27, 2012
