2.1.4 Mono/stereo
change-over
The MODE selector
[13]
determines wether
the input
signal is
switched to
mono or stereo
mode.
2.1.5
-2OdB
button
[30]
The volume can be reduced by
-20
dB by
pressing
button
[30].
The
volume setting and the indication
in
the display
[27]
will not
change.
This function
can be
cancelled by
pressing
the button
agarn.
2.1.6 Selecting
the audio source for the
tape outputs
(RE-
CORD OUTPUT buttons
[3]
through
[B])
These
buttons
select the signal source
that is to be
connected to
the tape outputs
(for
recording
purpose).
The
source
is always
connected to both outputs
(TAPE
1
OUT
and
TAPE 2 OUT).
A
programm
can be recorded
while llstening to a second
program
over the speakers.
When the
N/ONITOR
[3]
button
is
pressed (LED
above
is on),
the same
input is connected
to the tape
outputs that
has
been
selected
with the
MONITOR SELECTOR
buttons
[31]
trough
I
Jol.
When the button
TAPE COPY
[4]
is
pressed,
a
program
can
be
copied
f rom tape 1 to tape
2 or vice versa while simultaneously
listening to a different source,
e.g. a
record
being
played.
Procedure:
*
Set MONITOR switch
to tape on both units
(only
in this
posi-
tion can the
recorded signal be checked through the
amplifier.
-
Press TAPE COPY
[4]
on
amplifier.
-
Start
recorder containing
the
source tape
in
play
mode.
-
Start second
tape deck
in record mode.
-
To monitor the
quality
of the copy, select the tape
deck that
operates
in recording mode by
pressing
either MONITOR SE-
LECTOR button TAPE
1
[31]
or
TAPE 2
[34].
A different audio source
(tuner,
turntable.
etc,) can be
connect-
ed
to the
speakers
while copying from tape
to tape without
inter-
fering with the copy tunction.
qd/ox
-t
I
J
-l)d8
iiirEl
tuNe!
FtsoNo
r--r
r--
| r:-a r---"1
;
-._-MOS:iCF
SE.rriCR+
{; 1 ,'ll-r;
r.1
1üa|;1
roNt
*clllQo.
laPtz Drill
l3l
t41 tst 16l t7l t8l
INTRARED REMOT€
l&TrcLLE5
SYSIEM
r-t
tt
II
2.2Tone
control and filters
2.2.1 Tone
control
Extremelyf ine adjustment of the
sound color is
possible
with
the
potentiometers
BASS
[12]
and TREBLE
[11]
When
both
poten-
tiometers are in the right-hand limit
position,
the
frequency re-
sponse
is
compensated according to the loudness function.
Procedure:
-
Press TONE CONTROL
[37]
(LED
turns on)
-
Adjust for
the desired sound color with the
potentiometers
BASS
[12]
and TREBLE
[11].
-
The
tone control can be
enabled/bypassed
by
pressing
the
TONE
CONTROL
button
[37].
