Physical Data & Specifications
R96V Series
4
Physical Data and Specifications—Upflow Models
U.S. and Canadian Models
MODEL NUMBERS R96VA0402317MSA R96VA0602317MSA R96VA0702317MSA R96VA0852521MSB R96VA1002521MSA R96VA1152524MSA
HIGH FIRE INPUT BTU/HR [kW] ➀
42,000 [12.31] 56,000 [16.41] 70,000 [20.50] 84,000 [24.61] 98,000 [28.72] 112,000 [32.82]
LOW FIRE INPUT 29,400 [8.61] 39,200 [11.49] 49,000 [14.36] 58,800 [17.23] 68,600 [20.11] 78,400 [23.00]
HEATING CAPACITY BTU/HR [kW] 40,320 [11.82] 53,760 [15.75] 67,200 [19.68] 80,640 [23.63] 94,080 [27.57] 107,520 [31.51]
HIGH ALTITUDE OUTPUT
10% DERATE [kW] ➁
36,288 [10.64] 48,384 [14.18] 60,480 [17.72] 72,756 [21.27] 84,672 [24.81] 96,768 [28.36]
BLOWER (D x W)
[mm]
11 x 7
[279 x 178]
11 x 8
[279 x 203]
11 x 8
[279 x 203]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
11 x 11
[279 x 279]
MOTOR H.P. [W]–
TYPE
1/2 [373] E.C.M. 1/2 [373] E.C.M. 1/2 [373] E.C.M. 3/4 [559] E.C.M. 3/4 [559] E.C.M. 3/4 [559] E.C.M.
MOTOR FULL LOAD AMPS 8.9 8.9 8.9 10.8 10.8 10.8
MINIMUM EXT. STATIC PRESSURE
(IN. W.C.) [kPa]
.18 [.045] .20 [.050] .23 [.057] .28 [.070] .28 [.070] .28 [.070]
MAXIMUM EXT. STATIC PRESSURE
(IN. W.C.) [kPa]
1.0 [0.249] 1.0 [0.249] 1.0 [0.249] 1.0 [0.249] 1.0 [0.249] 1.0 [0.249]
HEATING CFM @ .2" [.049 kPa]
W.C. E.S.P. [L/s]
1050 [496] 1025 [484] 1015 [479] 1470 [694] 1710 [807] 1450 [684]
COOLING CFM @ .5" [.124 kPa]
W.C. E.S.P. [L/s]
1050 [496] 1050 [496] 1050 [496] 1750 [826] 1750 [826] 1750 [826]
TEMPERATURE RISE-HIGH FIRE
RANGE IN DEGREES °F [°C]
20 - 50
[11 - 28]
30 - 60
[17 - 33]
40 - 70
[22 - 39]
30 - 60
[17 - 33]
40 - 70
[22 - 39]
45 - 75
[25 - 42]
TEMPERATURE RISE-LOW FIRE
RANGE IN DEGREES °F [°C]
15 - 45
[8 - 25]
20 - 50
[11 - 28]
30 - 60
[17 - 33]
20 - 50
[11 - 28]
30 - 60
[17 - 33]
35 - 63
[19 - 36]
APPROX. SHIPPING WEIGHT
(LBS.) [kg]
128 [58] 128 [58] 132 [60] 147.5 [67] 152 [69] 165 [75]
AFUE ➂
96.00% 96.00% 96.00% 96.00% 96.00% 96.00%
NOTES: All models are 115V, 60HZ, 1 phase Gas connection size for all models is
1
/2" [13 mm] N.P.T.
➀ Installation instructions for high altitude derate.
➁ Canadian installations only.
➂ In accordance with D.O.E. test procedures.
*S=Standard Models
NOTE: Standard model complies with California low nox requirements.
[ ] Designates Metric Conversions
