6
“L”
“W”
“H”
ST-A1226-02-00
1
2
3
3.0 UNIT SPECIFICATIONS
Unit Specications
3.2 Electrical and Physical Data
Table 2: Electrical Data
Model
Number
(-)P18AZ
Phase
Frequency (Hz)
Voltage (Volts)
Compressor
Fan Motor
Full Load
Amperes (FLA)
Minimum Circuit
Ampacity Amperes
Fuse or HACR Circuit Breaker
Rated Load
Amperes (RLA)
Locked Rotor
Amperes (LRA)
Minimum
Amperes
Maximum
Amperes
24 1-60-208/230 15.4 35 1.9 21 25 30
36 1-60-208/230 24.0 50 1.8 32 40 50
48 1-60-208/230 28.1 50 1.2 34 50 60
60 1-60-208/230 31.7 50 2.0 42 50 60
Table 3: Physical Data
Model Number
(-)P18AZ
Outdoor Coil
Refrig. Per
Circuit Oz. [g]
Weight
Face Area
Sq. Ft. [m
2
]
No. Rows Net. Lbs. [kg] Shipping Lbs. [kg]
24 28.40 [2.6] 1 210 [5953] 278 [126] 282 [128]
36 32.44 [3.0] 1 212 [6010] 298 [135] 306 [139]
48 32.44 [3.0] 1 222 [6282] 298 [135] 306 [139]
60 32.44 [3.0] 1 252 [7144] 301 [137] 309 [140]
Model Number
(-A20
Outdoor Coil
Refrig. Per
Circuit Oz. [g]
Weight
Face Area
Sq. Ft. [m
2
]
No. Rows CFM [L/s] Net. Lbs. [kg] Shipping Lbs. [kg]
24 22.23 1 3328/1796/1264 148 (4195) 198 206
36 22.34 1 4313/2065/1050 1936 (5488) 236 244
48 32.45 1 6242/3212/1853 196 (5556) 255 263
60 32.45 2 6173/2932/1466 376 (10659) 300 307
Table 4: Dimensions
(-)P18AZ 24A 36A 48A 60A
Height "H" inches [cm] 45 [114.3] 51 [129.5] 51 [129.5] 51 [129.5]
Length "L' inches [cm] 35.75 [90.8] 35.75 [90.8] 35.75 [90.8] 35.75 [90.8]
Width "W" inches [cm] 35.75 [90.8] 35.75 [90.8] 35.75 [90.8] 35.75 [90.8]
(-)A18AZ 24A 36A 48A 60A
Height "H" inches [cm]
39 [91.1] 39 [91.1] 51 [129.5] 51 [129.5]
Length "L' inches [cm]
33.75 [85.7] 33.75 [85.7] 35.75 [90.8] 35.75 [90.8]
Width "W" inches [cm]
33.75 [85.7] 33.75 [85.7] 35.75 [90.8] 35.75 [90.8]
Figure 1: Unit Dimensions & Clearances
Item Number Item Description Clearance Needed
1 Air Inlet Louvers
6" [15.2 cm] All Sides
12" [30.5 cm] Recommended
2
Service Panels/ Inlet Connections /
High & Low Voltage Access
24" [61.0 cm]
3 Air Discharge 60" [152.4 cm]
Fuse or HACR Circuit Breaker
Compressor
Rated Load
Amperes
(RLA)
Locked Rotor
Amperes
(LRA)
Model
Number
(-)A18AZ
Phase
Frequency (Hz)
Voltage (Volts)
Fan Motor
Full Load
Amperes
(FLA)
Minimum
Amperes
Maximum
Amperes
24
36
48
60
1-60-208/230
1-60-208/230
1-60-208/230
1-60-208/230
15.0/15.0
20.1/20.1
32.0/32.0
34.1/34.1
35
35
50
50
1.4
3.5
5.3
5.3
25
35
60
60
35
45
70
80
