Electrical Components
SM 4-60 D245/D246/D247
 Make sure the EEPROM is correctly installed on the MPU.
4.14.2 EEPROM
1. Rear cover (page 4-6)
2. EEPROM [A]
 Make sure you print out the SMC reports ("SP Mode Data" and "Logging Data") before
you replace the EEPROM.
 Keep EEPROM away from any objects that can cause static electricity. Static electricity
can damage EEPROM data.
 Make sure the EEPROM is correctly installed on the MPU.
4.14.3 PSU (POWER SUPPLY UNIT)
1. Rear cover (page 4-6)
2. PSU [A] (
x 4, x 5)
