Engine SP Mode
SM 5-27 D245/D246/D247
Maintenance
5.2.3 SP3-XXX (PROCESS)
There are no Group 3 SP modes for this machine.
5.2.4 SP4-XXX (SCAN)
4008 [Sub Scan Mag Adj]
Adjusts the sub-scan magnification by changing the scanner motor speed.
4-008-001
- ENG [-1.0 to 1.0 / 0.0 / 0.1 % / step]
4010 [L-Edge Regist Adj]
Adjusts the leading edge registration for scanning.
4-010-001
- ENG [-2.0 to 2.0 / 0.0 / 0.1 mm / step]
4011 [S-Edge Regist Adj]
Adjusts the side-to-side registration by changing the scanning start timing in
the main scan direction.
4-011-001
- ENG [-2.0 to 2.0 / 0.0 / 0.1 mm / step]
4012 [FB Erase ForSP]
Adjusts scanning margins for the leading and trailing edges (sub scan) and
right and left edge (main scan) in the book scanning mode.
 Do not adjust unless the customer desires a scanner margin
greater than the printer margin.These settings are adjusted to
erase shadows caused by the gap between the original and the
scale of the scanner unit.
4-012-001
Book:LeadingEdge ENG [0.0 to 3.0 / 1.0 / 0.1 mm / step]
4-012-002
Book:TrailingEdge ENG [0.0 to 3.0 / 0.0 / 0.1 mm / step]
4-012-003
Book: Left ENG [0.0 to 3.0 / 1.0 / 0.1 mm / step]
4-012-004
Book: Right ENG [0.0 to 3.0 / 0.0 / 0.1 mm / step]
