Engine SP Mode
SM 5-36 D245/D246/D247
5.2.6 SP6-XXX (OPTION)
6006 [ADF Adjustment]
Adjusts the side-to-side and leading edge registration for simplex and
duplex original feeding in ARDF mode. SP6006-5 sets the maximum setting
allowed for rear edge erase.
6-006-001
SideEdge: Front *ENG [-3.0 to 3.0 / 0.0 / 0.1 mm / step]
6-006-002
SideEdge: Rear *ENG [-3.0 to 3.0 / 0.0 / 0.1 mm / step]
6-006-003
LeadingEdge:Front *ENG [-5.0 to 5.0 / 0.0 / 0.1 mm / step]
6-006-004
Leading Edge:Rear *ENG [-5.0 to 5.0 / 0.0 / 0.1 mm / step]
6007 [ADF Input Check]
See “page 5-42 "Input Check"”.
6008 [ADF Output Check]
See “page 5-44 "Output Check"”.
6017 [ADF Ajust Mag]
Adjusts the sub scan magnification at the DF scanning.
6-017-001 - *ENG [-5.0 to 5.0 / 0.0 / 0.1 % / step]
