Engine SP Mode

SM 5-4 D245/D246/D247

5.2 ENGINE SP MODE

5.2.1 SP1-XXX (PAPER HANDLING)

1001 [Sub Registration]

Leading Edge Registration Adjustment

(Tray Location, Paper Type, Color Mode), Paper Type: Plain, Middle Thick,

Thick

Adjusts the leading edge registration by changing the registration motor

operation timing for each mode.

Increasing a value: an image is moved to the trailing edge of paper.

Decreasing a value: an image is moved to the leading edge of paper.

1-001-002

Tray: Plain *ENG [-9.0 to 9.0 / 0.0 / 0.1 mm / step]

1-001-003

Tray: Mid Thick *ENG [-9.0 to 9.0 / 0.0 / 0.1 mm / step]

1-001-004

Tray: Thick *ENG [-9.0 to 9.0 / 0.0 / 0.1 mm / step]

1-001-007

Bypass: Plain *ENG [-9.0 to 9.0 / 0.0 / 0.1 mm / step]

1-001-008

Bypass: Mid Thick *ENG [-9.0 to 9.0 / 0.0 / 0.1 mm / step]

1-001-009

Bypass: Thick *ENG [-9.0 to 9.0 / 0.0 / 0.1 mm / step]

1-001-013

Duplex: Plain: *ENG [-9.0 to 9.0 / 0.0 / 0.1 mm / step]

1-001-014

Duplex: Mid Thick *ENG [-9.0 to 9.0 / 0.0 / 0.1 mm / step]

1-001-015

Duplex: Thick *ENG [-9.0 to 9.0 / 0.0 / 0.1 mm / step]

1002 [Main Registration]

Adjusts the printing side-to-side registration from each paper feed station,

using the “Test Page” in the [User Tools]. Adjustments are supported for all

five possible feed trays (including optional trays).

1-002-001

By-pass *ENG [-4.0 to 4.0 / 0.0 / 0.1 mm / step]

1-002-002

Tray Main1 *ENG [-4.0 to 4.0 / 0.0 / 0.1 mm / step]

1-002-004

Tray Bank1 *ENG [-4.0 to 4.0 / 0.0 / 0.1 mm / step]
