Ricoh D247 User Manual

Adjustment after Replacement
SM 4-70 D245/D246/D247
Tray SP No. Threshold
Duplex: Thick SP1-001-015
2. Check the side-to-side registration [B] for each paper feed station, and adjust them
using SP1-002.
Tray SP No. Threshold
By-pass SP1-002-001 2 ±1.5 mm
Tray Main1 SP1-002-002
Tray Bank1 SP1-002-004
Tray Bank2 SP1-002-005
Duplex SP1-002-006
Main Scan Magnification
 Use an S5S test chart to perform the following adjustments.
1. Check the magnification, and adjust the magnification using SP2-102-001
(Magnification Adjustment Main Scan) if necessary. The specification is ± 0.5%.
