A-14
1
Getting Started
Dimensions and Weight
• Weight:
5.5 kg (12.1 lb.)
• Dimensions:
Length: 362.5 mm (14.3 inches)
Height: 294.6 mm (11.6 inches)
Width: 124.3 mm (4.9 inches)
Environment
Environmental specifications Operating
Ambient temperature 5 °C to 40°C (41 °F to 104 °F)
Relative humidity 10% to 85% (non-condensing)
Altitude 3048 m (10,000 feet)
Connecting the Main Unit and Color Controller
Connect the main unit and Color Controller using the LAN cable provided with
the product.
If the LAN cable is too long for your usage environment, bundle the excess
amount by creating loops with a radius [1] of 10 cm (4 inches) or more as shown
in the figure below.
CAD003
