3. FAX Settings (M 320FB/320F only)
Fax Setup
Register the sender's information (this machine's number and name).
The target destination will receive faxes with the number and name registered in this setting.
1. Press [Process to Fax Setup].
ECC298
2. Enter [Fax Number:] and [Fax Name:], and then press [OK].
3. Press [Finish].
4. Press [Yes].
Connection
Connect a telephone line cord to LINE.
If using an external telephone, connect the telephone to TEL.
● Connect the public switched telephone network (PSTN) to Line. Connecting lines other than PSTN to this machine may cause
it to malfunction.
● Be careful not to connect the Ethernet cable by mistake.
2
1
1. Port For External Telephone
2. Port For LINE
If you connect a modular cable to the G3 (analog) line interface connector, make a loop 3 cm (1.2 inches) (1) from the end of the modular cable
(connection side to the machine) and attach the included ferrite core to the loops as shown.
To Next Page
