Introduction
Connection Ports
The interface is
subject to model’s
specications.
Compatible with
MHL version 2.2,
the charging current
5V@0.9A.
*HDBaseT
terminal is available
only for WUXGA
model.
N
o
t
e
1. HDMI 3/MHL terminal
(for dongle)
2. LAN terminal
3. Service terminal
(for rmware upgrade)
4. HDMI 1 terminal
5. HDMI 2/MHL terminal
6. Monitor Out terminal
7. S-Video In terminal
8. L/Mono/Audio1 In
terminal
1
2 3 4 5
15
6
7
8
9
1011121316
9. Audio2 In terminal
10. Audio Out terminal
11. R/Audio1 In terminal
12. Video terminal
13. PC Control terminal
14. Computer2 In terminal
15. Computer1 In terminal
16. HDBaseT terminal*
17. USB-A (5V@1A) terminal
1417
