4. ADF top cover [A] (two tabs, two hooks)

ADF Motor

1. ADF unit ( p.31)

2. Original Tray ( p.32)

3. ADF feed unit ( p.32)

4. ADF front cover ( p.33)

5. ADF rear cover ( p.34)

6. ADF drive unit [A] ( x 4, all s)

ADF
