- 13 -
INSTALLATION ENVIRONMENT
The CPS and the Battery Cabinet must be installed in ventilated, clean environments which are sheltered from bad weather.
The ambient temperature and relative humidity must not exceed the maximum values shown in the "T
ECHNICAL DATA” table.
Avoid installation in locations exposed to direct sunlight or hot air.
The recommended operating temperature for the product with the batteries is between 20 and 25°C.
Warning: an ambient temperature increase of 10 degrees will half the batteries expected life.
The CPS of category C2 if installed in a residential environment may cause radio interference, in which case
the user may be required to take additional measures.
For three-phase installation, this equipment complies with IEC 61000-3-12 provided that the short-circuit power
Ssc is greater than or equal to 2.94MW (7.4kA) at the interface point between the user's supply and the public
system. It is responsibility of the installer or the user to ensure that the equipment is connected to a supply with
the adequate short-circuit power Ssc (if required, consult the distribution network operator).
If the supply doesn’t meet the above requirements or if the requirements listed above are difficult to obtain, a
single-phase installation is suggested.
PLACEMENT
When installing the equipment, the following points should be considered:
the wheels are to be used exclusively for fine positioning, and thus for small distances only.
the plastic parts and the front panel are not to be used for gripping or pushing.
enough space should be left in front of the equipment for it to be turned on/off and maintenance operations to be
performed on it (1.5 m)
the rear part should be set at least 30 cm from the wall, to enable the air blown by the ventilation fans to flow away
correctly and to allow access to the disconnector switches
no objects should be left on its top surface
check that the room containing the batteries is ventilated in compliance with EN 50272-2 paragraph 8.2
