- 26 -
CPS CONFIGURATION
The table below illustrates all the possible configurations available to the user in order to best adapt the CPS for individual
requirements. It is possible to perform these operations using the configuration software. For more detailed information
regarding the additional features refer to the software manual.
FUNCTION DESCRIPTION DEFAULT
Operating mode Selects the operating modes ON LINE
Output voltage
Selects the rated output voltage
(Phase - Neutral)
230 V
Output nominal frequency * Selects the rated output frequency 50 Hz
Autorestart
Waiting time for automatic power-on after the return of mains
voltage
5 s
Auto power off
Automatic CPS power-off in battery operation mode if the
load is lower than 5%
Disabled
Buzzer Reduced Selects the audible alarm operating mode Reduced
EnergyShare off Selects the operating mode of EnergyShare sockets
Always connected (**)
Timer Programmed CPS power ON/OFF (daily) Disabled
Autonomy limitation Maximum battery operation time Disabled
Maximum load Selects the user overload limit Disabled
Bypass Synchronization speed
Selects the synchronisation speed of the inverter to the
bypass line
1 Hz/s
External temperature Activates reading of the external temperature probe Disabled
Bypass mode * Selects the mode of use of the bypass line
Enabled /
High sensitivity
Bypass active in stand-by Load supply from bypass with CPS in stand-by
Disabled (load NOT
supplied)
