INTRODUCTION
The Agility version-3-compatible 2-Way Wireless Slim Keypad comes in two models:
RW132KL1P—a black protection-insulated outdoor model empowered with a
proximity reader
RW132K1 — a white indoor model
operates in either of two modes:
• Full function Mode: Wireless LED operating keypad
• Bypass unit Mode: Used to activate an entry countdown period
Being bi-directional the 2-Way keypad receives a reply status indication from the panel
for each command that it has sent to the panel.
To use functions of the keypad you can use a proximity tag (1P only) or a code.
Main Features
Bi-directional wireless communication
Up to three wireless keypads per system
Power-save light sensor
Proximity tag operation
Wall tamper protection
Battery economy mode
Wireless doorbell function
2 operation modes
(1P) outdoor certified IPXXXX
COMMUNICATION SETUP
The 2-Way Slim Outdoor Keypad must identify itself to the system receiver. This can be
done by entering the 11-digit serial number of the keypad into the system or using RF
mode.
Setup communication:
1. Set the system to Learn Mode by RF or by Code.
2. Send an allocation message *.
♦ By RF communication: Send a Write message by pressing both keys
simultaneously for at least 2 seconds.
♦ By Code: Enter the keypad's 11 digit serial code number
3. The system automatically recognizes the device and allocates it the next available
index number. The system will announce the keypad device type and the place it
has been allocated to.
4. If required to change the keypad's default settings, configure the keypad's
parameters according to the system installation manual.
