12
Mute Circuit
This is an anti-thump, mute and delay circuit that eliminates irritating, speaker-damaging turn-on and turn-off transients normally experienced with less expensive ampliers.
Bass Remote
The dash-mounted bass remote allows you to control the amplier’s bass level from the comfort of the driver’s seat. It features a power LED which indicates the unit is receiving power
and operating nominally. Refer to “Power and Protection Circuitry” on page 14 for detailed information.
Battery Voltage
Rockville dB Mini Series ampliers are rated and regulated to 13.8 volts and below. Increasing voltage to 14.4 volts will increase the power output of the amplier in the same proportion.
Maximum input voltage is 14.4 volts while the minimum voltage is 12 volts.
DO NOT EXCEED 14.4V INPUT VOLTAGE.
Specifications
dB10
• Dyno Certied RMS Power Output
4 Ohm: 360 Watts x 1 Channel <1% THD+N
• Peak Power Output
4 Ohm: 720 Watts x 1 Channel
• Low Pass Filter: 50Hz – 250Hz
• Subsonic Filter: 15Hz – 55Hz
• Phase Shift: 0 - 180
• Minimum THD at Rated Power: <0.1%
• S/N Ratio: >60dB
• Frequency Response: 15Hz – 250Hz
• Damping Factor: >60 @ 100Hz
• 25 Amp ATO Fuse
• Dimensions: (W x H x L) 5.5˝ x 2.0˝ x 7.7˝
dB11
• Dyno Certied RMS Power Output
2 Ohm: 700 Watts x 1 Channel <1% THD+N
4 Ohm: 440 Watts x 1 Channel <1% THD+N
• Peak Power Output
2 Ohm: 1400 Watts x 1 Channel
4 Ohm: 880 Watts x 1 Channel
• Low Pass Filter: 50Hz – 250Hz
• Subsonic Filter: 15Hz – 55Hz
• Phase Shift: 0 - 180
• Minimum THD at Rated Power: <0.1%
• S/N Ratio: >60dB
• Frequency Response: 15Hz – 250Hz
• Damping Factor: >60 @ 100Hz
• 40 Amp ATO Fuse
• Dimensions: (W x H x L) 5.5˝ x 2.0˝ x 8.9˝
Features (continued)
