Rockville dB11 User Manual

2
Thank you for purchasing this Rockville dB Mini Series amplier. Over the years, the technology used to create audio ampliers has grown by leaps and bounds. Our competition is
satised with just continuing to build the same units year after year without thought for improvement, but not Rockville. We consider it our mission to use our expertise in developing the
latest technologies and to bring you the absolute best sounding ampliers on the market and of course at a reasonable price. You will be amazed at the quality and power that these new
amps offer. We have spared no expense in designing these ampliers, creating the most rugged, reliable, powerful and best performing ampliers. In fact we are so sure of the quality we
backup every dB Mini Series amplier with one year warranty which exemplies our commitment to the end user. (See enclosed warranty card for details.) Please read this installation
guide carefully for proper use of your dB Mini Series amplier. Read this entire guide fully before attempting your installation. Should you need assistance, please call our technical help
line at 1-646-758-0144, Monday through Thursday, 9am to 10pm EST, and Fridays, 9am to 3pm EST.
WARNING: BE AWARE! Use of this amplifier at extreme high volumes for extended periods of time may cause hearing loss and or hearing damage. During periods of prolonged
high volume levels it is recommended that you use ear safety devices. Your ability to hear necessary traffic sounds will be impaired. While driving always keep your sound
volume at reasonable levels. We at Rockville want you listening for many years to come.
• When installing the amplier, secure it tightly. An unmounted amplier in your car can cause serious injury to passengers and damage to your vehicle if it is set in motion by an abrupt
driving maneuver or short stop.
• To reduce risk of electric shock, never open the unit. There are no user serviceable parts, refer service to an authorized Rockville service center.
• Do not expose this unit to any kind of moisture.
• Please ensure that the unit is situated in a properly ventilated area.
Introduction
IMPORTANT SAFETY INSTRUCTIONS

Rockville dB11 Specifications

General

S/N Ratio	>90dB
LPL (Low Pass Filter)	50Hz - 250Hz
Low Pass Filter	50Hz - 250Hz
Input Sensitivity	0.2V - 6V
Bass Boost	0-18dB @ 45Hz
Phase Shift	0-180 Degrees
