Rockwell Automation Allen-Bradley 5069-AENTR User Manual

Rockwell Automation Publication 5069-UM007A-EN-P - February 2019 23
Chapter 3
Connect to the EtherNet/IP Network
You must set the IP address on the adapter for the adapter to operate on an
EtherNet/IP network.
The following are adapter conditions in which you set the IP address:
• Set the IP address for the first time after it powers up in the
out-of-box state.
• Change the IP address after it has been set.
Set the IP Address
When the adapter is in the out-of-the-box state, the following apply regarding
IP addresses:
• The adapters ship without an IP address.
• The rotary switches on the adapter are set as follows:
– 5069-AENTR adapter - 999
– 5069-AEN2TR adapter - 000
Topic Page
Set the IP Address 23
Set the IP Address with the Rotary Switches 24
Other Methods to Set the IP Address 25
Reset the 5069-AENTR Adapter 26
Reset the 5069-AEN2TR Adapter 26
IMPORTANT The adapter powers up in the out-of-box the first time you install it.
However, the adapter also after power is cycled and the adapter is
configured to clear its IP address after power is cycled.
