Roland A-88 User Manual

Driver Installation
23
Verify That You Can Hear Sound
After you’ve installed the driver, check to verify that the driver was installed correctly.
We will use SONAR LE as an example for Windows, and GarageBand as an example for Mac OS X.
Checking with a SONAR Soft Synths (Windows)
Here’s an example using a plug-in synth included with SONAR LE. The procedure or screens may
dier if you’re using a dierent version.
For details on installing and setting up SONAR LE, refer to the SONAR LE Installation Guide.
1. Start up SONAR LE.
2. In the [Edit] menu, click [Preferences]; then in the menu at left, click [Devices] in the
MIDI area.
The “Select MIDI input and output devices” dialog box will appear.
3. Choose the following MIDI devices in the [Inputs] and [Outputs] elds.
Input device Output device
A-Series Keyboard A-Series Keyboard MIDI OUT
If you’re unable to select A-Series Keyboard as an input/output device, it may be that a problem
has occurred. Refer to “Problems When Using the Unit” (p. 49).
4. Click [Apply] and then [Close] to close the “Select MIDI input and output devices”
dialog box.
5. In the [File] menu, click [New].
The “New Project File” dialog box will appear.
6. In the “Template” area, choose [Normal];
then enter a project name in the “Name”
eld and click [OK].
7. In the [Insert] menu, choose [Soft Synths] and then [Square I].

Roland A-88 Specifications

General

Control type	Buttons, Rotary
Number of knobs	2
MIDI-keyboard number of keys	88 keys
Product color	Black
Interface	USB
DC-in jack	Yes
Power source type	DC

Weight and Dimensions

Depth	273 mm
Width	1443 mm
Height	116 mm
Weight	15900 g
