Roland FA-06 Service Notes

9
Feb. 2014 FA-06
Plane View (2)
fig.bunkaizu-view-34.eps
View 3
View 4
h hg
g gg
gg
g g
View 3
View 4
No. Part Code Part Name Description Q’ty
g 40011312 SCREW 3X8 BINDING TAPTITE P FE BZC 54
h 5100023206 SCREW 2.6X8(JC7000220R0) BINDING TAPTITE P ZC 5
No. Part Code Part Name Description Q’ty
g 40011312 SCREW 3X8 BINDING TAPTITE P FE BZC 9

Roland FA-06 Specifications

General

Control type	Buttons
Backlight color	Red
Backlight buttons	Yes
MIDI-keyboard number of keys	61 keys
Display type	LCD
Display diagonal	5 \
Product color	Black
Sound effects	Acoustic resonance, Synthesizer
Interface	USB
Headphone outputs	1
USB ports quantity	2
Compatible memory cards	SDHC
6.35 mm (1⁄4-inch) output	3
Power source type	AC
Bit rate	16 bit
Product type	Digital synthesizer
Keyboard number of keys	61
Maximum polyphony (notes)	128
Reverberation effects quantity	6

Weight and Dimensions

Depth	300 mm
Width	1008 mm
Height	101 mm
Weight	5700 g
