Settings for the Entire FANTOM
166166
Parameter Value Explanation
Hold Pedal
Hold Pedal
Polarity
STANDARD,
REVERSE
Selects the polarity of the pedal
connected to the PEDAL HOLD jack.
Depending on the model of pedal, the
result of depressing or releasing the
pedal might be the opposite of what
you expect. If so, choose the “REVERSE”
setting. If you’re using a Roland pedal
(that has no polarity switch), choose
the “STANDARD” setting.
Continuous
Hold Pedal
OFF, ON
If this is ON, the PEDAL HOLD jack will
support half-pedaling. If half-pedaling
is enabled, you can connect a damper
pedal (such as the DP-10; available
separately) and use the pedal to
control subtle nuances of the piano
sounds you play.
Wheel Settings
(WHEEL 1/2)
Parameter Value Explanation
Wheel Assign
Source
SYS, SCENE
Species whether the functions
controlled by the wheels are
determined by the system settings
(SYS) or by the settings of the scene
(SCENE).
Assignable
Wheel1–2
Assign
Assign the functions controlled by the wheels.
OFF No function is assigned.
CC01–31,
33–95
Controller number 1–31, 33–95
BEND
The same eect as moving the pitch
bend lever.
AFT Aftertouch
Wheel1–2
Range Min
0–127
Specify the lower limit value for the
range of the assigned function.
Wheel1–2
Range Max
0–127
Specify the upper limit value for the
range of the assigned function.
S1/S2 Settings
(S1/S2)
Parameter Value Explanation
S1, S2 Assign
Source
SYS, SCENE
Species whether the functions
controlled by the [S1] and [S2] buttons
are determined by the system settings
(SYS) or by the settings of the scene
(SCENE).
Parameter Value Explanation
Assignable
S1, S2 Switch
Assign
Assign the functions controlled by the [S1] and [S2]
buttons.
OFF No function is assigned.
CC01–31,
33–95
Controller number 1–31, 33–95
BEND DOWN
The same eect as moving the pitch
bend lever to the left.
BEND UP
The same eect as moving the pitch
bend lever to the right.
AFT Aftertouch
MONO/POLY Mono/poly switch is assigned.
MFX SW MFX on/o is assigned.
EQ SW EQ on/o is assigned.
IFX1 SW IFX1 on/o is assigned.
IFX2 SW IFX2 on/o is assigned.
CHORUS SW CHORUS on/o is assigned.
REVERB SW REVERB on/o is assigned.
MASTER
COMP SW
MASTER COMP on/o is assigned.
MASTER EQ
SW
MASTER EQ on/o is assigned.
VOCODER SW VOCODER on/o is assigned.
SCENE DOWN
Switches to the scene of the previous
number. When using a scene chain,
switches to the previous number
within the chain set.
S1, S2 Switch
Assign
SCENE UP
Switches to the scene of the next
number. When using a scene chain,
switches to the next number within
the chain set.
DEC
Applies the same eect as pressing the
panel [DEC] button.
INC
Applies the same eect as pressing the
panel [INC] button.
START/STOP Plays back the sequencer.
GROUP PLAY
DOWN
Selects the previous group in the
group list.
GROUP PLAY
UP
Selects the next group in the group
list.
SONG LOOP
SW
Turns the song loop on/o.
TFX SW Turn the TFX on/o.
MASTER KEY
DOWN
Adjusts the Master Key Shift value by
-1.
MASTER KEY
UP
Adjusts the Master Key Shift value by
+1.
SCALE TUNE
SW
Turns the SCALE TUNE on/o.
VTW ROTARY
SPEED
Alternates between SLOW and FAST.
VTW ROTARY
BRAKE
Alternately switches the brake on/o
for the rotary eect.
VTW ROTARY
SW
Turns the rotary eect ON/OFF.
VTW
OVERDRIVE
SW
Turns the overdrive ON/OFF.
VTW WHEEL
BRAKE
Alternately switches the brake on/o
for the tonewheel.
VTW VIB/CHO
SW
Lets you switch the vibrato and chorus
on/o.
VTW
HARMONIC
BAR
You can also use the sliders as
harmonic bars on other screens
besides the edit screen.
Settings can be made for only the
[S1]–[S3] buttons.
