Roland FC-300 User Manual

29
Patch Mode
This mode is used for storing combinations of multiple MIDI messages that you can
combine freely and transmitting these messages together in groups.
This mode allows you to control the settings for multiple devices, all just with the
FC-300.
A “patch” is a group of multiple MIDI messages (MIDI stream) and other settings
that are configured together as a single unit. The FC-300 can store up to 100
individual patches.(p. 44)
The patch can set the following parameters.
• Patch’s ON Stream
Group of MIDI messages transmitted when a patch is selected.
• Patch’s OFF Stream
Group of MIDI messages transmitted when a different patch is selected or
when a pedal is released. These are used for canceling settings from ON
streams.
• Timing for transmission of the patch’s OFF stream
• CTL1,2 ON streams
These are the groups of MIDI messages transmitted when the pedals are
switched on.
• CTL1,2 OFF streams
These are the groups of MIDI messages transmitted when the pedals are
switched off.
• AMP CONTROL
You can set the status of the AMP CONTROL jacks when a patch is selected.
• Control pedal, expression pedal, and other settings
• Patch names
* An individual patch can hold MIDI messages containing up to a maximum of
approximately 500 bytes. Although the total amount of MIDI message data that can be
stored in Patch Mode is approximately 8 Kbytes, this amount of memory is shared by all
patches. Therefore, please note that not all patches can contain the full approximately 500
bytes.
About the Patch Mode
About the Patch
When a patch name is set, the
patch name is indicated in the
top screen in Patch Mode.
Patch Number Patch Name
A “MIDI stream” is a number
of MIDI messages grouped
together.
FC-300_e1.book 29 ページ ２００７年４月２４日 火曜日 午前１０時１０分
