9
TD-12
PARTS LIST
fig.part1e
fig.lithium.eps
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
NOTE: The parts marked # are new. (initial parts)
Due to one or more of the following reasons,
parts with parts code ******** cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
The description "Q'TY" means a necessary number of the parts per one product.
For EU Countries
Apparatus containing Lithium batteries
ADVARSEL!
Lithiumbatteri - Eksplosionsfare ved
fejlagtig håndtering.
Udskiftning må kun ske med batteri af
samme fabrikat og type.
Levér det brugte batteri tilbage til
leverandøren.
VARNING
Explosionsfara vid felaktigt batteribyte.
Använd samma batterityp eller en
ekvivalent typ som rekommenderas av
apparattillverkaren.
Kassera använt batteri enligt
fabrikantens instruktion.
CAUTION
Danger of explosion if battery is
incorrectly replaced.
Replace only with the same or
equivalent type recommended by the
manufacturer.
Discard used batteries according to the
manufacturer’s instructions.
ADVARSEL
Eksplosjonsfare ved feilaktig skifte av
batteri.
Benytt samme batteritype eller en
tilsvarende type anbefalt av
apparatfabrikanten.
Brukte batterier kasseres i henhold til
fabrikantens instruks joner.
VAROITUS
Paristo voi räjähtää, jos se on
virheellisesti asennettu.
Vaihda paristo ainoastaan
laitevalmistajan suosittelemaan
tyyppiin. Hävitä käytetty paristo
valmistajan ohjeiden mukaisesti.
CASING
# 03891845 BOTTOM COVER 1
# 03891867 DISPLAY COVER 1
# 03891878 LED COVER 1
# 03891923 RUBBER SW ESCUTCHEON 1
03453845 D S-ESCUTCHEON SX4H-A BLK L=30 1
# 03891934 D S-ESTC SX2H-A BLK L=30 1
# 03891990 TOP PANEL 1
CHASSIS
# 03891890 LCD HOLDER 1
# 03891889 PWR SPLY HOLDER 2
# 03891978 PWB HOLDER MAIN 3
KNOB, BUTTON
12499175 BUTTON JSPUE001A 1
03125589 M R-KNOB MF-ELA BLK/LCG 3
22485303 D R-KNOB(ALPHA-DIAL) L BLK 248-303 1
22485295 D S-KNOB S BLK/LCG 6
# 03891989 RUBBER SW 1
SWITCH
01676512 PUSH SWITCH SDKLA10200 SW101 JAB 1
01340290 TACT SWITCH EVQ11A H=5.0 SW19,SW18,SW17,SW15,SW13,SW11,SW7,
SW4,SW6,SW5,SW20,SW9,SW2,SW22,SW2
3,SW24,SW25,SW16,SW14,SW12,SW8,SW1,
SW3,SW21,SW10 PAB
25
13129734 SWITCH(PUSH) SKHCAD SW26,SW27 PAB 2
JACK, EXT TERMINAL
00569278 6.5MM JACK LGR4609-7100 JK103,JK105,JK104,JK106,JK102 JAB ,JK1 on
MAB
,JK16,JK10,JK13,JK12,JK11,JK14,JK17,JK18,J
K19,JK20,JK15,JK8,JK9 TRB
13
+5
+1
13429676 MIDI CONNECTOR YKF51-5048 (TWIN) JK101 JAB 1
DISPLAY UNIT
03230690 SCLCMEAMNI0065 LCD 1
NOTE: Replacement SCLCMEAMNI0065 should be made on a unit base.
01342534 SL-9351S LED 7 SEGMENT LED5 PAB 1
NOTE: Replacement SL-9351S should be made on a unit base.
POWER SUPPLY UNIT
03782334 A1DU2L3B184 SWITCHING REGULATOR 1
NOTE: Replacement A1DU2L3B184 should be made on a unit base.
To Next Page
