14
4. Expanding the drum kit
Connecting an extra tom pad (PD-85: sold separately)
Use a stereo cable to connect the PD-85 to the TD-9 as shown in the illustration.
1. Attach the Pad Mount (MDH-10U : sold separately) to the stand.
2. Connect the cable included with the
pad to the TD-9’s AUX jack.
There are dierent ways to expand the size of the TD-9K2/9KX2 to adapt to your playing style.
By adding a V hi-hat, you can enjoy the same playing feel and expressiveness as with an acoustic
hi-hat.
Expansion examples
Pad Mount
(MDH-10U : sold separately)
from PD-85
Crash cymbal (CY-8)
Tom (PD-85)
Hi-hat (VH-11)
The TD-9 comes with the toms and crash cymbals
shown in this illustration. And it’s easy to expand the
conguration.
