15
Panel Descriptions
S/P DIF OUT Connector
The XV-5080 features both optical and coaxial digital out
connectors (conforming to S/P DIF).
S/P DIF: This is a digital interface format used for consumer
digital audio devices.
* About the Optical Connector Protecting Cap
• If you remove the protecting cap, be sure to keep in a
safe place to prevent loss.
• Always place the protecting cap on the optical connector
when the connector is not in use.
• If you use the optical connector, be sure that the
connector cover you removed is placed out of the reach
of children.
Q
SCSI Connector
This is a DB-25 type SCSI connector for connecting SCSI
devices such as a CD-ROM drive, a Zip disk drive or a hard
disk drive.
Rotate the ID switch to set the SCSI ID numbers so that none
of the devices have the same ID number. (p. 239)
* On the XV-5080, “8” and “9” of the ID switch are not used.
To Next Page
