Royal Enfield Himalayan User Manual

Royal Enfield Himalayan 119
TROUBLESHOOTING
We have listed below a few basic checks in case your motorcycle is not functioning. If in case the problem is not rectified
after these checks, it is necessary to get the motorcycle checked by a Royal Enfield Authorised Dealer/ Service Centre to
rectify the problem and to ensure trouble free performance.
Symptom Observations Check for/Remedy
Engine does not start
If the ignition/Engine kill switch in OFF
position
Switch ON ignition
If inadequate fuel level in fuel tank Top up the fuel
If the lights are dim/weak horn sound
Weak or discharged battery / problem in
charging circuit Contact Authorised service
center
If fuse is blown
1. Replace the fuse with same rating
2. Contact Authorised service center if prob-
lem persists
Connection issue with spark plug, cap,
high tension cable
Reconnect spark plug, cap and high tension
cable.

Royal Enfield Himalayan Specifications

General

Engine Type	Single Cylinder, 4 stroke, Air cooled, SOHC
Displacement	411 cc
Max Power	24.3 bhp @ 6500 rpm
Max Torque	32 Nm @ 4000 - 4500 rpm
Fuel System	Electronic Fuel Injection
Transmission	5-speed constant mesh
Front Suspension	Telescopic, 41 mm forks, 200 mm travel
Rear Suspension	Monoshock with linkage, 180 mm wheel travel
Front Brake	300 mm disc, 2-piston floating caliper
Fuel Tank Capacity	15 liters
Seat Height	800 mm
Ground Clearance	220 mm
Kerb Weight	199 kg
Bore x Stroke	78 mm x 86 mm
Compression Ratio	9.5:1
Clutch	Wet, multi-plate
Frame Type	Half-duplex split cradle frame
Tyre Size (Front)	90/90 - 21
Tyre Size (Rear)	120/90 - 17
Wheelbase	1465 mm
Rear Brake	240mm disc, single-piston floating caliper
ABS	Dual Channel ABS (Switchable)
